control knob (Fig. 8 1) and turn it to the large Electric hot plate (depending on model) FITTED EQUIPMENT
flame position (Fig. 8 2).
Fig 9
• S imultaneously ignite the burner with a
match or gas lighter. NOTE: When the electric hot plate is turned
on for the first time, or if it has not been
• Once the flame has been generated, press used for some time, the absorbed humidity
the knob down for a few seconds so that the must be removed by turning the plate on for
flame remains lit. 30 minutes on position 1 of the knob (Fig.
9 1). Use cookware with a flat bottom and
! WARNING: with a diameter smaller than the diameter
electric hotplate.
If the burner does not turn on:
! WARNING:
• check that there is gas in the cylinder.
Dry the bottom of the cookware before
If the device does not work, close the gas placing it on the electric hotplate. When
inlet tap and contact your dealer. using the hot plate, do not leave the
appliance unattended and make sure
Regulating the grill flame children are not nearby.
• T o adjust the flame, turn the knob to the The electric hot plate is controlled by a 7-
desired position (Fig. 8 1). position knob (Fig. 9 2 : the off position is
represented by the 0 (zero), while the positions
Visual inspection of the flame from 1 to 6 are used to operate the electric hot
plate. The scale from 1 to 6 corresponds to
Depending on the type of gas used, the flame the increasing heat intensity generated by the
appears as follows: electric hot plate. There is a red LED light near
the knob that lights up when the electric hot
• Propane (G31): flame with blue internal pin plate is in operation (Fig. 9 3).
point and clear outline. Accessories
• B utane (G30): flame with slight yellow tips
when igniting the burner; these tips intensify
as the burner heats.
Fig 10 175
The rack and drip pan have a block that
prevents accidental extraction (Fig.10 1).
For a correct insertion, the blocks must be
facing upwards and toward the inside of the
appliance. To extract, slightly lift the front of
the rack or the drip pan.
