FITTED EQUIPMENT Powered Bed Mechanism
(model specific)
Once the bed reaches the desired position,
If fitted to your motorhome, a touch button turn the key to the OFF position, turning it to
symbol provides control for a motorised bed the left by 90° and remove it.
mechanism, allowing a bed to be adjusted
between either two, or three, differing heights. Note:
There are various types of protection.
Two Position Bed Mechanism • The key for isolation of operation
• T wo or three limit switches, one high and
The bed is operated from a small aluminium
panel with a security key and two buttons. the other low.
One to move the plane of the bed upwards, • Mechanical Movement
the other downwards.
! WARNING: The bed operating mechanism
Insert the key into the lock and turn clockwise
by 90 °. should only be operated by a responsible
Press the top button to lift the bed. The bed adult.
moves as long as the button is pressed. Take care to ensure that all persons, pets
Press the bottom button to lower the bed. and loose items are clear of the top and
The bed moves downward as long as the user underside of the bed before operating the
holds down the button. lifting mechanism.
The lifting-bed system is equipped with two Do not operate the lifting mechanism with a
or three limit switches for protection. If for person or heavy object on the bed.
example the user holds the down button for Always remove the key when the bed lifting
a longer time than that required for the bed mechanism is not in use.
to travel its full drop then, a protection device
takes over and disables the movement so as Manual Operation
not to exit the bed from the guides and also to
protect the motor. The electric motor is fitted on the end with a
This protection is replicated for the upward 13mm hexagonal nut, which allows manual
movement. movement of the plane of the bed in case
of insufficient voltage of the vehicle leisure
battery. The bed mechanism can be operated
manually, if power is disabled. Locate the
13mm nut, which is accessible through either
the under locker or under bed moulding,
via an access hole. Using a 13mm socket,
turn the hexagonal nut clockwise or counter
clockwise, depending on the desired direction
of movement.
