TABLES
Care points Table storage FITTED EQUIPMENT
Care must be taken to remove obstructions Tables stored in the table storage
which will restrict the full range of movement compartment must be securely clipped into
of the motorised drop-down bed fitted to place whilst in transit.
Motorhomes.
To avoid damage care must be taken when
If an object left in the way when the bed is removing tables from their stored position.
lowered then the bed will not reach it’s pre-set
bottom stop position. The motor will continue ! WARNING: Tables infront of forward facing
to run, unwinding the belts until they loop back
on themselves and begin to raise the bed passengers must be stowed in the storage
despite the ‘lower’ button being depressed position when the vehicle is moving
If this happens, the remedy to this is to then Care of laminate tops, tables,
press the ‘raise’ button, which will effectively furniture and doors
re-wind the belts and eventually raise the bed
once the slack has been taken up. Do not use abrasives, chemically treated
cloths or aggressive detergents as these may
Tables cause damage
Note: The free standing table legs have a Do not place hot objects on laminated
positive locking mechanism. Care must be surfaces i.e. tops, tables. Any temperatures
taken to ensure that, when folded, the leg 70°C and over will cause permanent damage.
which is closed first locks into the second
position. Clean worktop surfaces, furniture and door
fascias with a soft, slightly damp cloth, dry off
When engaging legs in down position the with a soft cloth.
mechanism must be positively locked down.
! WARNING: When erecting the free
standing table, be careful to avoid trapping
fingers.
211
