WINDOWS

FITTED EQUIPMENT  Windows                                           The same phenomenon may also occur
                                                                    when washing your vehicle on a hot day.
                  Seitz Window Systems                              The condensation should clear itself when
                                                                    the ambient conditions return to normal and
                  To open, depress the button on the handle         the air between the panes dries. However, if
                  (not on Kon-Tiki) and turn the handle, the        this is taking a longer time than required, the
                  majority rotate anti-clockwise with one handle    breathable plug (normally located in the top
                  on the right stay that will rotate clockwise.     corner of the window) can be removed, with
                                                                    a pin or sharp object, and replaced when the
                  Once all catches are open swivel the window       panes are dry. Care should be taken when
                  pane open to the desired position.                doing this.
                  These positions are set by a ratchet on the
                  stay, it has 3 pre-set positions. To close, open
                  the window all the way past the last position
                  and it will then close.

                  All opening windows have two catch positions.
                  The first position is for ventilation the second
                  seals the window from ventilation and rain.

                  Kon-Tiki Polyvision Acrylic Windows               Acrylic (Plastic) Window Cleaning

                  To open, turn knobs anti-clockwise and open       The material used to produce most
                  catches. Swivel the window pane open to the       motorhome windows is acrylic plastic. While
                  desired position and close knobs clockwise to     the acrylic used is very durable, it is able to
                  lock in the open position.                        be scratched with relative ease and therefore,
                                                                    care must be taken when cleaning your vehicle
                  To close, reverse the operation.                  not to use aggressive cleaning products.

                  All opening windows have two catch positions.     Equally, care should be taken when using a
                  The first position is for ventilation the second  drying cloth that it is clean and free from grit.
                  seals the window from ventilation and rain.
                                                                    Plastoform Window System
                  Window Condensation
                                                                    Within these instructions you will be able to
                  Kon-tiki windows are not vacuum sealed.           find information to most common questions
                  Instead the double panes of acrylic plastic are   about correct usage of PLASTOFORM Blanca
                  fitted with a breathable plug on the inner pane.  windows. If you can’t find the information you
                                                                    need here, please contact us directly on email:
                  It is possible, in weather where extremes         blanca@plastoform.si
                  in temperatures occur between night and
                  day, that customer will notice condensation       While Driving
                  between the panes.
                                                                    When vehicle is in motion all windows must be
                                                                    fully closed.

194
