Use C-402C, C-402X and C-403L
12. R un water into the bowl by pressing the
flush knob briefly or open the valve blade
by turning the handle anti-clockwise. Your
Thetford toilet is now ready for use.
13. A fter us, open the valve blade (if still
closed) by turning the handle anti-
clockwise. Flush the toilet by pressing the
flush knob for several seconds. Close the
valve blade after use.
Note: Do not leave water in the bowl if the
toilet is not being used. This does not help
to reduce unpleasant smells and only leads
to flooding.
Note: To prevent clogging, we recommend
using Aqua soft, Thetford’s quickly dissolving
toilet paper.
! WARNING: Please do not travel with a
flush water tank that is too full (we advise
empty) but not filled more than half full.
Do not travel with water in the toilet bowl.
Failure to adhere to this notice may result in
water damage to yxour motorhome.
Emptying
The waste tank has a capacity of 19 litres
and must be emptied at the latest when the
red light in the level display lights up. The
indicator lamp will light up when the waste
tank can still take about two litres, which is
about three uses.
Note: Do not allow the waste tank to
become too full.
Use C-402C, C-402X and C-403L
14. M ake sure that the valve blade is closed.
Open the access door located outside the
vehicle. Pull the safety catch upwards and
remove the waste tank.
15. R emove the water filling extension first to the upper plug.
avoid it getting lost during the emptying of
the waste tank.
16. Stand the waste tank upright (pull out FITTED EQUIPMENT
handle at the top, wheels at the bottom).
Press the handle down and move it away
from the waste tank until it snaps out of its
locked position.
17. P ull the handle up and wheel the waste
tank to an authorised waste dump.
17. Pull the handle up and wheel the waste
tank to an authorised waste dump.
18. Push the handle back. Turn the emptying
spout upwards and remove the cap from
the spout. Hold the waste tank by the
upper handle with one hand, while placing
your other hand by the rear handle so that
during emptying you can operate the vent
plunger with your thumb.
To empty the tank without splashing,
depress the vent plunger while emptying
the tank. After emptying, flush the tank
thoroughly with water. Also clean the valve
blade with water.
Note: The vent plunger should only be
pressed once the emptying spout is pointing
downwards!
19. If required make the toilet ready for
use once again. Return the water filing
extension to its original position on the
waste tank. Slide the waste tank into the
toilet and close the access door.
Storage
It is important that you follow the instructions
below if you do not expect the Thetford toilet
for a long period.
Completely empty the water tank through
the drain tube, which also serves as a level
indicator. Take the drain tube out of the clamp
and carefully pull it downwards from the upper
plug. Direct the drain tube out through the
access door opening to allow water to flow
out. Afterwards, be sure the drain tub is placed
back into the clamp first and then pushed into
189
