THETFORD C400 CASSETTE TOILET
Thetford C400 Cassette Toilet o. A utomatic pressure release valve: ventilates FITTED EQUIPMENT
the waste tank when this located in the
These operating instructions cover Thetford cassette toilet. Avoids excessive pressure in
cassette toilet models C-402C, C-402X and the waste tank.
C-403L. There are a few differences in the use
of these models. Make sure that you follow the p. P ull-out handle: for easy transport of the
instructions that apply to your toilet model. waste tank.
The parts and functions that are referred to by q. Wheels
letters are illustrated in later pages.
r. R otating emptying spout: ensures that the
The actions to be taken, referred to by waste tank can be easily and hygienically
numbers, are illustrated are also illustrated in emptied.
page 192.
s. Water filling extension
Parts and functions
C-402C and C-402X t. Access hatch to waste tank and water
filling funnel: lockable from the outside of the
a. Handle: opens and shuts the valve blade vehicle.
b. F lush knob: when this pressed, an electric C-402L
pump fills the bowl with water
a. Handle: opens and shuts the valve blade.
c. L evel indicator display: the red LED on the
display lights up when the waste tank is full b F lush knob: when pressed a central
(C-402C and C-402X). When the flush know electric pump in the vehicle pumps water
is pressed briefly, the display shows the into the bowl.
level in the waste tank and the level in the
water tank (C-402X). c. Level indicator display: the red LED on the
display lights up when the waste tank is full.
d. R emovable seat and cover When the flush knob is pressed briefly, the
display shows the level in the waste tank.
e. C over plates
d. R emovable seat and cover
f. S torage compartment for toilet fluids (only
the tall model) e. Cover plate
g. Safety catch: holds the waste tank in place f. Storage compartment for toilet fluids (only
the tall models)
h. W ater filling tunnel: for easy filling of the
water tank. g. Safety catch: holds the waste tank in place.
i. Cover: guarantees optimal hygiene. Opens h. Cover: guarantees optimal hygiene. Opens
when the waste tank is located in the toilet when the waste tank is located in the toilet.
and closes when the waste tank is removed.
i. Removable mechanism
j. Removable mechanism
j. Valve blade opener
k. Valve blade opener
k. Valve blade / Valve seal
l. V alve blade / valve seal
l. Vent plunger: for emptying without splashing.
m. Vent plunger: for emptying with splashing.
m. Automatic pressure release vent: ventilates
n: U pper handle the waste tank when this is located in the
cassette toilet. Avoids excessive pressure
in the waste tank. 187
n. Upper handle: for easy emptying
o. P ull-out handle: for easy transport of the
waste tank.
p. Wheels
