AWNINGS
If you want to fasten the support legs to
the vehicle, put the terminals into the wall
brackets. The brackets can be fixed only in
reinforced points.
! WARNING: We recommend that the
awning be ground mounted only. Side
mounting brackets are supplied. But in
inclement weather conditions it may cause
damage to the motorhome bodywork.
! WARNING: The awning is a sun
protection, please roll up your awning in
case of rain, wind or snow. Alternatively
lower one side of your awning, so that water
can flow away and assemble the tension
rafter as shown in the figure (not included for
all awning lengths).
Make sure that the awning perfectly rolls
up: when it is, the red indicators on the front
profile ends are no longer visible. A damaged
fabric does not allow the awning to perfectly
roll up. Never use the awning with a damaged
canopy. Wash the canopy with Fiamma BRILL.
Note: In case of problems refer to the
awning user manual or contact your dealer.
Suggestions for use and maintenance for
the fabric of your awning.
Fiamma fabrics are made with PVC and
Polyester layers and their properties can
change in certain weather conditions.
For example, if you close the awning which
has been opened in the sun for a long time,
wrinkles can appear on the fabric.
In low temperature, the fabric becomes FITTED EQUIPMENT
less pliable and there is a risk of cracks.
Please find here a list of some practical
advice for the best and long lasting use of
your awning:
1. O pen and close the awning in normal
condition of dampness and temperature
(at night or in the morning) making sure
the fabric has no sharp objects on it and is
clean.
2. W hen closing the awning after a long
period in the sun, wrinkles may appear and
prevent the awning closing completely.
In this case the security of the awning is
not compromised, as the security winch
will prevent accidental opening. If wrinkles
appear re-open the awning and leave in
the sun for some hours and the folds will
disappear. Then of course you need to re-
close the awning in normal conditions (see
point 1).
3. Residual damp can cause spots on the
fabric. If the awning has to be closed when
the fabric is damp we suggest you re-open
it as soon as possible to dry.
4. We suggest you avoid using the awning
below 0°C.
5. W hen closing the awning you should
support the front bar.
6. M ost of the dirt seen on the fabric will
be superficial and can be cleaned with
water and a cloth. Stubborn marks can be
removed using a light detergent. Please do
not use aggressive chemical substances
and do not use high pressure cleaning tools.
203
