P. 122

Set time switch                                   12hour mode                                      FITTED EQUIPMENT

 ! WARNING:                                       Entering the end time
                                                  • S et the hours then the minutes with the
 Danger of toxic exhaust fumes.
 The activated time switch switches on the          rotary push button.
 heater even when the vehicle is parked.          24hour mode
 The heater’s exhaust can be toxic in closed
 spaces (e.g. garages, workshops). If the         12hour mode
 vehicle is parked in closed rooms:

 • Shut off the fuel supply (gas or diesel) to
   the heater.

 • Deactivate the time switch of the Truma
   CP plus control panel (OFF).

 • Switch off the heater on the Truma CP
   plus control panel.

 Note:
 • When air conditioning systems are being

   operated, the time switch of the Truma CP
   plus control panel must only be used to
   clearly define the start and end time for a
   required period of time.

 • If the time switch has been activated
   (ON), the deactivate time switch menu is
   displayed first (OFF).

• S elect icon in menu bar (4) with rotary push
  button.

• Change by tapping in the setting level.

Enter start tme
• Set the hours then the minutes with the

  rotary push button.

24hour mode

                                                  Note: If the start/end point was exceeded
                                                  during entry, the operating parameters are
                                                  not taken into consideration until the next
                                                  start/end point has been reached. Until then,
                                                  the operating parameters that have been set
                                                  outside the time switch remain valid.

                                                  Set the room temperature                         109

                                                  • Select the heater, air conditioning system
                                                    or AUTO using the rotary push button,
                                                    depending on the appliance that is
                                                    connected.

                                                  • Tap rotary push button to confirm selection.

                                                  • Select required room temperature with rotary
                                                    push button.
