P. 118
Start-Up Switch off FITTED EQUIPMENT
• P ress rotary push button for longer than 4
Start/Stand by screen
After connecting the control panel to the seconds.
power supply, a start screen is shown after a • “OFF” appears after another 2 seconds.
few seconds. • T he Truma CP plus control panel
Note: deactivation procedure can be delayed by
• The display changes between the time several minutes because of internal heating
or air conditioning system after-runs.
and the set room temperature. Change the room temperature
• Special displays on command via • S elect icon in menu bar (3) with rotary push
button.
Truma App, IR remote control of the • Change by tapping in the setting level.
air conditioning system (see “Special • Depending on the appliance that is
displays” on page 113). connected, select between heating system
• A fter a repair / retrofit, the procedure (HEATER) or air conditioning system (AC) or
described under “Initial start-up” must be automatic air conditioning system1 (AUTO)
repeated. using the rotary push button.
• Tap rotary push button to confirm selection.
Functions • S elect desired temperature with rotary push
button.
The functions in the menu bars (3, 4) of the • Tap the rotary push button to confirm the
Truma CP plus control panel are selectable value.
in any order. The operating parameters
are shown on the status bar (2) and on the Heater
displays (5, 6). Settable temperature range 5 - 30°C
Select setting level (1°C steps)
• Tap rotary push button. a = heater2 – Heater is switched on.
The display shows the setting level. The first Air conditioning system (AC)
icon flashes. (when connected/when AC is fitted)
Settable temperature range 16 – 31°C
Switching on and off (1 °C steps)
Switch on b = COOL* - A ir conditioning system is
• Tap rotary push button.
• Previously set values / operating parameters switched on
c = AUTO - A ir conditioning system is set to
are reactivated after switching on
automatic
d = HOT - Air conditioning system is in 105
heating mode.
e = VENT - Air conditioning system is in air
circulation mode
